SHVM15F Semtech DIODE GEN PURP 15KV 500MA MODULE
SHVM15F Images
SHVM15F Images
  • Manufacturer: Semtech
  • Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single Package / Case: Module
  • Description: DIODE GEN PURP 15KV 500MA MODULE
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
SHVM15F Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
SHVM15F Specifications:
  • Manufacturer Product Number: SHVM15F
  • Mfr: Semtech Corporation
  • Detailed Description: DIODE GEN PURP 15KV 500MA MODULE
  • Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single
  • Package: Bulk
  • Series: -
  • Part Status: Active
  • Diode Type: Standard
  • Voltage - DC Reverse (Vr) (Max): 15000 V
  • Current - Average Rectified (Io): 500mA
  • Voltage - Forward (Vf) (Max) @ If: 42 V @ 800 mA
  • Speed: Standard Recovery >500ns, > 200mA (Io)
  • Reverse Recovery Time (trr): 2 µs
  • Current - Reverse Leakage @ Vr: 1 µA @ 15000 V
  • Capacitance @ Vr, F: -
  • Mounting Type: Chassis, Stud Mount
  • Package / Case: Module
  • Operating Temperature - Junction: -55°C ~ 150°C
  • SHVM15F Semtech, DIODE GEN PURP 15KV 500MA MODULE, Discrete Semiconductor Products~Diodes - Rectifiers - Single
SHVM15F, Semtech authentic parts in stock from Semtech authorized distributors, order today, can ship immediately.
