ECLAMP2506K.TCT Images
- Manufacturer: Semtech
- Category: Filters~EMI-RFI Filters (LC, RC Networks) Package/Case: 12-UFDFN Exposed Pad
- Description: FILTER LC(PI) 17NH/12PF ESD SMD
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ECLAMP2506K.TCT Specifications:
- MfrPart.: ECLAMP2506K.TCT
- Mfr: Semtech Corporation
- Description: FILTER LC(PI) 17NH/12PF ESD SMD
- Product Category: Filters~EMI-RFI Filters (LC, RC Networks)
- Package: Tape & Reel (TR)
- Series: EMIClamp®
- PartStatus: Obsolete
- Type: Low Pass
- FilterOrder: 3rd
- Technology: LC (Pi)
- NumberofChannels: 6
- Center/CutoffFrequency: 250MHz (Cutoff)
- AttenuationValue: 20dB @ 800MHz ~ 2.7GHz
- Resistance-Channel(Ohms): 18
- Current: -
- Values: L = 17nH, C = 12pF
- ESDProtection: Yes
- OperatingTemperature: -40°C ~ 85°C
- Applications: Data Lines for Mobile Devices
- Voltage-Rated: -
- MountingType: Surface Mount
- Package/Case: 12-UFDFN Exposed Pad
- Size/Dimension: 0.098 L x 0.051 W (2.50mm x 1.30mm)
- ECLAMP2506K.TCT Semtech, FILTER LC(PI) 17NH/12PF ESD SMD, Filters~EMI-RFI Filters (LC, RC Networks)
ECLAMP2506K.TCT, Semtech authentic parts in stock from Semtech authorized distributors, order today, can ship immediately.
