1N5809 Semtech DIODE GEN PURP 100V 6A AXIAL
1N5809 Images
1N5809 Images
1N5809
  • Manufacturer: Semtech
  • Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single Package / Case: Axial
  • Description: DIODE GEN PURP 100V 6A AXIAL
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
1N5809 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
1N5809 Specifications:
  • Manufacturer Product Number: 1N5809
  • Mfr: Semtech Corporation
  • Detailed Description: DIODE GEN PURP 100V 6A AXIAL
  • Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single
  • Package: Bulk
  • Series: -
  • Part Status: Active
  • Diode Type: Standard
  • Voltage - DC Reverse (Vr) (Max): 100 V
  • Current - Average Rectified (Io): 6A
  • Voltage - Forward (Vf) (Max) @ If: 875 mV @ 4 A
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Reverse Recovery Time (trr): 30 ns
  • Current - Reverse Leakage @ Vr: 5 µA @ 100 V
  • Capacitance @ Vr, F: 60pF @ 5V, 1MHz
  • Mounting Type: Through Hole
  • Package / Case: Axial
  • Operating Temperature - Junction: -
  • 1N5809 Semtech, DIODE GEN PURP 100V 6A AXIAL, Discrete Semiconductor Products~Diodes - Rectifiers - Single
